3530V

FFP3, Valved Respirator. Disposable with Pre-Formed Cup Shape

Product Features

Lightweight, cup shaped respirator
Four point headstrap adjustment
Preformed nosebridge removes the need for regular adjustment
Electrostatic filter media
Soft touch elastic
PVC Foam Inner Face Seal
Conforms to EN 149:2001+A1:2009 FFP3 NR
Low Profile Exhalation Valve helps reduce heat and moisture build up

Certifications

CAT III

Declaration of Conformity

Datasheet

User Information Sheet

Skytec Respiratory FFP Guide

Manufacturing Construction Healthcare Food Production Maritime

Battery Manufacturing Craft and Hobbies Gardening Metal Fabrication Work Disease and Infection Control Handling Hazardous and Toxic Waste Woodwork and Fabrication

Features

Unique Inner Face Seal Made in the UK

Further Information

The 3500 SERIES disposable respirators offer an outstanding level of protection demonstrated when conducting Face Fit Testing. Having electrostatic filter media allows low breathing resistance and a lightweight outer shell maintains excellent shape.

Product Specifics

Filter Media Material	Non-Woven Textile
Headstrap Material	Latex-Free Elastane, Polyester, Textile Elastic
Inner Cover Material	Polypropylene
Nosefoam Material	Polyethylene Foam
Outer Cover Material	Polypropylene
Series	3500

Storage Conditions

Humidity	<70%
Maximum Temperature	35°C
Minimum Temperature	-5°C

Certifications

CE	✓
Cat Level	III
EN 149:2001 + A1:2009	FFP3 NR

EN 149:2001

Class	FFP3
Disposable	✓

Selected Option Specifics

SKU	ASR35301AZ
Size	One-Size
Main Colour	White
Secondary Colour	Orange
Shelf Life	5Years

Ordering information

Items per Pack	5
Case Quantity	100
Packs Per Case	20
Units per Pallet	1600

Packaging

Unit Height	150mm
Unit Length	210mm
Unit Width	125mm
Pack height	15cm
Pack length	21cm
Pack width	12.5cm
Weight	19g
Pack weight	0.19kg
Case height	32cm
Case length	65cm
Case width	44cm
Case weight	4.58kg

Product Selector Guidance Chart

Option	Assigned Protection (APF)	Oil/Water Based Particulates	Non-Toxic Dusts	Fine Toxic Dusts/Mists/Fumes	Very Fine Toxic Dusts/Mists/Fumes	Metal Fume
ASR35301AZ	20	Recommended	Alternative	Alternative	Recommended	Recommended

Parts Dimensions

Part	Width	Length	Height
Exhalation Valve	34 mm	37 mm	8 mm
Headband Clip	19 mm	37 mm	4 mm
Headband	14 mm	420 mm	0.4 mm
Nosebridge	40 in	45 in	35 in
Respirator	60 mm	150 mm	130 mm

Recommendations for Use

USER INSTRUCTIONS: Use only in accordance with these instructions, as incorrect use could result in danger to life or health. Fit according to instructions BEFORE entering the contaminated area. Discard safely after use or replace with a new respirator if: • Excessive clogging of the respirator causes breathing difficulty or discomfort • If the respirator becomes damaged • The respirator has been worn for 8 hours. Do not use in oxygen deficient, (less than 19%), explosive atmospheres or confined spaces where gases or aerosols may accumulate and the concentration of contaminant is immediately dangerous to life or health, (over the IDLH value). Leave the contaminated area if: • The respirator is damaged • You become dizzy or have difficulty breathing • You become irritated or other distress occurs • You become uncertain of the nature and/or concentration of contaminant. WARNING: • As facial hair reduces the protection offered it is recommended that these respirators are used by clean shaven personnel only • Do not use for protection against gases • Single shift use only • Do not remove whilst in contaminated area.
