Navigator

The Navigator is a Set of Safety Eyewear in a Classic Style Frame Available in a Choice of 6 Lenses Options Including 3 Coloured Revo, Polarised & Grey

Product Features

Conforms to EN 166
Iconic fashion design
4 base curve lens
Dual injected temples with soft tips
Available in 6 lens options including 3 revo coloured options polarised & grey
Anti-fog/anti-scratch lens coatings
Non-safety fashion option also available
Supplied in premium box packaging & microfibre pouch

Certifications

Options

Lens Colour

Declaration of Conformity

Datasheet

User Information Sheet

Highways and Infrastructure Automotive Construction Manufacturing Home and Garden

Component and Product Assembly Vehicle Repairs and Maintenance Commercial Cleaning Infrastructure Engineering General Maintenance Inspection and Quality Control

Features

Sports Style

Further Information

Innovative yet iconic, the Riley Navigator offers a stylish solution to safety eyewear protection. The unique 4-base curve design combines classic contemporary sunglass styling with full safety features, allowing workers to experience retail design with protection in the workplace.

Available Options

Lens Type	Product Code	Lens Marking	Frame Marking	Protects Against	Coatings
Red Fire Revo Mirror	RLY00527	5-2.5 1 FT Z87+ U6 L2.5 S I 2	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067	Impacts UV Radiation Solar Radiation	Arida 400 UV400 Moisture Repellent
Polarised	RLY00520	5-3.1 1 FT Z87+ U6 L3 S I 3	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067	Impacts UV Radiation Solar Radiation	Arida 400 UV400 Moisture Repellent
Grey	RLY00522	5-3.1 1 FT K N Z87+ U6 L3 S I 3	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067	Impacts UV Radiation Solar Radiation	Tecton 400 UV400 Moisture Repellent
Antique Mirror/Revo	RLY00525	5-3.1 1 FT Z87+ U6 L3 S I 3	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067	Impacts UV Radiation Solar Radiation	Arida 400 UV400 Moisture Repellent
Clear	RLY00526	2C-1.2 1 FT K N Z87+ U6 S IO 0	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067	Impacts UV Radiation	Tecton 400 UV400 Moisture Repellent
Blue Ice Revo Mirror	RLY00529	5-3.1 1 FT Z87+ U6 L3 S I 3	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067	Impacts UV Radiation Solar Radiation	Arida 400 UV400 Moisture Repellent

Product Specifics

Frame material	Polycarbonate
Frame Type	Full Frame
Hinge Material	Polycarbonate, Metal
Nosebridge Material	Thermoplastic Rubber (TPR)
Series	Navigator
Temple Material	Polycarbonate, Thermoplastic Elastomers (TPE)

Certifications

CE	✓
EN 166	✓
ANSI Z87.1	✓
AS/NZS 1337.1:2010	✓

Options

Selected Option Specifics

SKU	RLY00527
Main Colour	Black
Lens Coating	Arida 400, UV400, Moisture Repellent
Frame Marking	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067
Lens base	4mm
Lens Marking	5-2.5 1 FT / Z87+ U6 L2.5 S / I 2
Lens Colour	Red Fire Revo Mirror
Protects Against	Impacts, UV Radiation, Solar Radiation
VLT (Visible Light Transmission)	26%

SKU	RLY00520
Main Colour	Black
Lens Coating	Arida 400, UV400, Moisture Repellent
Frame Marking	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067
Lens base	4mm
Lens Marking	5-3.1 1 FT / Z87+ U6 L3 S / I 3
Lens Colour	Polarised
Protects Against	Impacts, UV Radiation, Solar Radiation
VLT (Visible Light Transmission)	12%

SKU	RLY00522
Main Colour	Black
Lens Coating	Tecton 400, UV400, Moisture Repellent
Frame Marking	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067
Lens base	4mm
Lens Marking	5-3.1 1 FT K N / Z87+ U6 L3 S / I 3
Lens Colour	Grey
Protects Against	Impacts, UV Radiation, Solar Radiation
VLT (Visible Light Transmission)	14%

SKU	RLY00525
Main Colour	Black
Lens Coating	Arida 400, UV400, Moisture Repellent
Frame Marking	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067
Lens base	4mm
Lens Marking	5-3.1 1 FT / Z87+ U6 L3 S / I 3
Lens Colour	Antique Mirror/Revo
Protects Against	Impacts, UV Radiation, Solar Radiation

SKU	RLY00526
Main Colour	Black
Lens Coating	Tecton 400, UV400, Moisture Repellent
Frame Marking	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067
Lens base	4mm
Lens Marking	2C-1.2 1 FT K N / Z87+ U6 S / IO 0
Lens Colour	Clear
Protects Against	Impacts, UV Radiation
VLT (Visible Light Transmission)	92%

SKU	RLY00529
Main Colour	Black
Lens Coating	Arida 400, UV400, Moisture Repellent
Frame Marking	EN166 F CE UKCA Z87+ AS/NZS 1337.1 Lic. SMK41067
Lens base	4mm
Lens Marking	5-3.1 1 FT / Z87+ U6 L3 S / I 3
Lens Colour	Blue Ice Revo Mirror
Protects Against	Impacts, UV Radiation, Solar Radiation
VLT (Visible Light Transmission)	55%

Ordering information

Items per Pack	5
Case Quantity	50
Packs Per Case	10

Packaging

Unit Height	80mm
Unit Length	156mm
Unit Width	50mm
Pack height	8cm
Pack length	27cm
Pack width	16cm
Weight	30g
Pack weight	0.55kg
Case height	20cm
Case length	86cm
Case width	29cm
Case weight	6.4kg

EN 166:2001

SKU	Lens Colour	Filter	Tint	Optical Class	Mechanical Strength	Additional Markings	Frame Mechanical Strength
RLY00527	Red Fire Revo Mirror	5Solar filter	2.5Grey or Revo	1For Continuous Work	FLow-energy Impact TExtreme temperatures		FLow-energy Impact
RLY00520	Polarised	5Solar filter	3.1Dark Grey or Mirror	1For Continuous Work	FLow-energy Impact TExtreme temperatures		FLow-energy Impact
RLY00522	Grey	5Solar filter	3.1Dark Grey or Mirror	1For Continuous Work	FLow-energy Impact TExtreme temperatures	KResistance to Scratching NResistance to Fogging	FLow-energy Impact
RLY00525	Antique Mirror/Revo	5Solar filter	3.1Dark Grey or Mirror	1For Continuous Work	FLow-energy Impact TExtreme temperatures		FLow-energy Impact
RLY00526	Clear	2CUV w/ colour	1.2Clear or Amber	1For Continuous Work	FLow-energy Impact TExtreme temperatures	KResistance to Scratching NResistance to Fogging	FLow-energy Impact
RLY00529	Blue Ice Revo Mirror	5Solar filter	3.1Dark Grey or Mirror	1For Continuous Work	FLow-energy Impact TExtreme temperatures		FLow-energy Impact

ANSI/ISEA Z87.1

SKU	Lens Colour	Impact Rating	UV Light Rating	Additional Markings
RLY00527	Red Fire Revo Mirror	Z87+High Velocity Impact	U6	SSpecial Tint Lens
RLY00520	Polarised	Z87+High Velocity Impact	U6	SSpecial Tint Lens
RLY00522	Grey	Z87+High Velocity Impact	U6	SSpecial Tint Lens
RLY00525	Antique Mirror/Revo	Z87+High Velocity Impact	U6	SSpecial Tint Lens
RLY00526	Clear	Z87+High Velocity Impact	U6	SSpecial Tint Lens
RLY00529	Blue Ice Revo Mirror	Z87+High Velocity Impact	U6	SSpecial Tint Lens

Disposal

Pitted, scratched or damaged lenses must be replaced by replacing the complete product. If the frame is damaged also replace the complete product.

Cleaning

The lenses should be cleaned regularly.

Storage

All products must be stored in a dry and clean environment. After each use it is recommended to keep the spectacles or goggles in a microfibre pouch or rigid case.
